MD1 MD Prep Phase 1 · page viewer
10 · SMB3 · Cardio, respi & rénal · 10.14 · Hématose et rapports V/Q · all pages
All subjects / 10 · SMB3 · Cardio, respi & rénal

10.14 · Hématose et rapports V/Q

Gas exchange and V/Q relationships

Système respiratoire · 47 pages · 6 sections

All pagesPage view

All pages overview. This static page is crawlable without JavaScript and exposes every page image directly.

Open original PDF
Jump by section
10.14.01Hématose et rapports V/Q — p. 1–8p. 1–810.14.02Hématose et rapports V/Q — p. 9–16p. 9–1610.14.03Hématose et rapports V/Q — p. 17–24p. 17–2410.14.04Hématose et rapports V/Q — p. 25–32p. 25–3210.14.05Hématose et rapports V/Q — p. 33–40p. 33–4010.14.06Hématose et rapports V/Q — p. 41–47p. 41–47
